Overview Capacity 12000‎ Capacity (Cooling, kW) 3.52‎ Capacity (Heating, Btu/hr) 12000‎ Capacity (Heating, kW) 3.52‎ Capacity Capacity (Cooling, Btu/hr) 12000‎ Capacity (Heating, Btu/hr) 12000‎ Capacity (Cooling, Min - Max, Btu/hr) 3050 - 13600‎ Capacity (Heating, Min - Max, Btu/hr) 2700 - 17000‎ Capacity (Cooling, kW) 3.52‎ Capacity (Heating, kW) 3.52‎ Capacity (Cooling, Min - Max, kW) 0.89 - 3.99‎ Capacity (Heating, Min - Max, kW) 0.79 - 4.98‎ Energy Efficiency EER (Cooling, W/W) 2.44‎ COP (Heating, W/W) 3.63‎ EER (Cooling, Btu/hW) 8.33‎ COP (Heating, Btu/hW) 12.37‎ Noise Level Noise Level (Indoor, High/Low, dBA) 38/19‎ Noise Level (Outdoor, High/Low, dBA) 46‎ Electrical Data Power Source(Φ/V/Hz) 1 / 220~240 / 50‎ Power Consumption(Cooling, W) 1440‎ Power Consumption(Heating, W) 970‎ Operating Current(Cooling, A) 6.3‎ Operating Current(Heating, A) 4.4‎ Physical specification Gross Dimension (Indoor, WxHxD, mm*mm*mm) 880 x 290 x 375‎ Gross Dimension (Outdoor, WxHxD, mm*mm*mm) 834 x 620 x 323‎ Net Dimension (Indoor, WxHxD, mm*mm*mm) 820 x 299 x 215‎ Net Dimension (Outdoor, WxHxD, mm*mm*mm) 710 x 540 x 220‎ Gross Weight (Indoor, kg) 10.2‎ Gross Weight (Outdoor, kg) 26.4‎ Net Weight (Indoor, kg) 8.9‎ Net Weight (Outdoor, kg) 22.5‎ Loading Quantity (20/40/40Hft without Pipe) 105 / 212 / 252‎ Technical Information Piping Length (Max, m) 15‎ Piping Height (Max, m) 8‎ SVC Valve (Liquid (ODxL)) 6.35‎ SVC Valve (Gas (ODxL)) 9.52‎ Moisture Removal (l/hr) 1.40‎ Air Circulation (Cooling, m3/min) 10.50‎ Refrigerant (Type) R32 Refrigerant (Charging, kg) 0.53‎ Refrigerant (Charging, tCO2e) 0.36‎ Low Ambient (Cooling, ℃) -10~46‎ Low Ambient (Heating, ℃) -15~24‎ Outdoor Unit (Compressor Type) BLDC Outdoor Unit (Anti-Corrosion Fin) Yes Air Flow WindFree Cooling No Air Direction Control (Up/Down) Auto Air Direction Control (Left/Right) Auto Air Flow Control Step (Cool/Fan) 5/4‎ Air Purification PM 1.0 Filter No Tri Care Filter No 4-in-1 Care Filter No Copper Anti-bacterial Filter Yes Auto Clean (Self Cleaning) Yes Convenience SmartThings Yes AI Auto Cooling Yes Motion Detect Sensor No Freeze Wash No Filter Cleaning Indicatior Yes Indoor Temp. Display Yes Display On/Off Yes Beep On/Off Yes 24-Hour Timer Yes Auto Changeover Yes Auto Restart Yes Operating Mode Auto Mode Yes Fast Cool Yes Dry Comfort No Good Sleep Yes Eco Mode Yes Max-Ampere Control Yes Dehumidification Yes Fan Mode Yes Quiet Yes Smart WiFi Embedded Yes
